Modbus, Profinet and Profibus are three widely used industrial communication protocols, each with its own role. Modbus is a simple, vendor-neutral protocol for sensors, meters and links. Profibus is an established field bus for process and factory automation. Profinet is the more modern Industrial-Ethernet standard that succeeds Profibus and offers higher speeds and more flexible networking. The choice depends on speed, topology, existing equipment and the requirements of your process.
For engineers and buyers, protocol selection is rarely trivial. Existing PLCs, vendor ecosystem and installed base weigh as heavily as technical specifications. Below you will read what each protocol is, followed by a direct comparison and consideration for the choice in a custom controller.
Table of Contents
Modbus: simple and widely supported
Introduced in 1979 by Modicon, Modbus is an open, royalty-free protocol. Thanks to that simplicity and openness, it is supported by virtually every manufacturer. It has two main variants:
- Modbus RTU: Serial communication over RS-485 or RS-232, in a bus topology.
- Modbus TCP: Same message structure, transported over standard Ethernet.
Modbus operates on a master/slave model (now client/server) and is polling-based. That makes it not deterministic in the hard real-time sense: it is excellent for reading sensors, energy meters and simple field devices, but less so for time-critical control such as motion control. The strength of Modbus is its combination of simplicity, low cost and universal support, which keeps it relevant for interconnections even in new installations.
Profibus: the established fieldbus
Profibus (Process Field Bus) originated in 1989 from Siemens and the PI (PROFIBUS & PROFINET International) organization, and is defined in IEC 61158/61784. It is a deterministic field bus with a large installed base. Profibus has two main variants:
- Profibus DP (Decentralized Peripherals): high-speed factory automation over RS-485, up to 12 Mbit/s.
- Profibus PA (Process Automation): for the process industry, intrinsically safe and suitable for explosion hazard zones (ATEX), where field devices can be powered via the same two-wire connection. PA is slower at 31.25 kbit/s, but robust in demanding environments.
Profibus uses a line/bus topology with termination resistors and master/slave operation with token passing between masters. It is mature and proven, but is increasingly being succeeded by Profinet in new projects. However, the large existing base makes Profibus relevant for a long time to come, especially in the process industry.
OPEN CALCULATION
OFFER IN 5 DAYS
SUSTAINABLE INNOVATIONS
UL/CSA
IN HOUSE
Profinet: industrial Ethernet as successor
Profinet is the Industrial-Ethernet standard from the same organization (PI) and is considered the successor to Profibus. It runs on standard Ethernet (IEEE 802.3) with regular cabling and switches, but adds deterministic mechanisms for control. Profinet has two relevant real-time classes:
- RT (Real-Time): For the vast majority of automation applications.
- IRT (Isochronous Real-Time): deterministic with very low jitter, for time-critical applications such as motion control.
Profinet supports flexible topologies (star, line, ring) and media redundancy via MRP. With speeds from 100 Mbit/s to Gigabit, comprehensive diagnostics and seamless integration with IT networks, it is the logical choice for modern machine and plant automation. The downside is a slightly more complex setup, and IRT requires managed switches.
Comparison Chart: Modbus, Profibus and Profinet
| Aspect | Modbus | Profibus | Profinet |
|---|---|---|---|
| Type | Open serial/ethernet protocol | Fieldbus | Industrial Ethernet |
| Provenance | Modicon, 1979, vendor-neutral | PI/Siemens, 1989 | PI/Siemens, successor to Profibus |
| Medium | RS-485/RS-232 (RTU), Ethernet (TCP) | RS-485 (DP), MBP (PA), fiber optic | Standard Ethernet (copper/fiberglass) |
| Topology | Bus (RTU), star/switched (TCP) | Line/bus with terminating resistors | Flexible: star, line, ring (with switches) |
| Speed | RTU up to about 115 kbit/s, TCP at Ethernet speed | DP up to 12 Mbit/s, PA 31.25 kbit/s | 100 Mbit/s to Gigabit |
| Real-time | Non deterministic (polling) | Deterministic | RT and IRT (deterministic) |
| Communication model | Master/slave (client/server) | Master/slave, token passing | Provider/consumer, cyclic + acyclic |
| Application | Sensors, meters, interfaces, legacy | Established process and plant automation | Modern machine/plant automation, motion, IT/OT |
| Status | Mature, widely supported | Mature, large installed base | Modern, growing |
Legacy versus new: how do they compare?
It helps to see the three protocols not as separate competitors, but in their interrelationship:
- Profinet succeeds Profibus. Both come from PI. In new installations, Profinet is gaining ground, while Profibus is still in full operation thanks to its installed base. Coupling between the two is possible via proxy or gateway modules.
- Modbus is independent of this. It is an independent, open protocol often used alongside Profinet or Profibus to connect simple equipment or equipment from other vendors.
- OPC UA operates at a higher level. It does not replace these field protocols, but complements them for unambiguous data exchange and IT/OT integration above the control layer. For interfacing between PLC and SCADA, this is often the preferred route.
In practice, multiple protocols co-exist in a single installation. The question then is not “which protocol is best,” but “which protocol fits which component, and how do we link them reliably.”
Contact our experienced innovator
Cees Brasser
With more than 26 years of experience at the helm of Kwadrant IA, Cees Brasser is your expert on panel construction for the mechanical engineering sector. Discover how his knowledge and insight can take your project to new heights. Get in touch now!
Protocol selection in a custom control
A protocol is not an end in itself, but a design choice in the larger control system. Industrial automation requires more than just a correctly constructed panel: the choice of Modbus, Profibus or Profinet is related to the existing equipment, vendor ecosystem, performance requirements and desired scalability.
In Kwadrant IA, operating systems are not built around a single protocol, but around the application. The consideration proceeds along a set of fixed questions:
- What controls and field devices are already in place? Existing PLCs and service contracts often set the stage.
- How time-critical is the process? For motion control, IRT (Profinet) is obvious; for reading meters, Modbus suffices.
- What kind of environment is the installation running in? In hazardous areas, Profibus PA or an intrinsically safe solution is relevant.
- What data should be available company-wide? For IT/OT integration and interfacing with SCADA, OPC UA comes to mind.
Because hardware engineering, software engineering and panel building come under one roof at Kwadrant IA, the choice of protocol is included from the design phase and worked out in the software in a structured way according to IEC 61131-3. This creates not a standard solution, but a controller in which communication is reliably tailored to the process.
Want to learn more about how these protocols work together with the control and visualization layer? Then also read our article on what a SCADA system is and how it relates to a PLC.
